Shandong Heze Sanyi Biological Engineering Co., Ltd. is one of the leading manufacturers and suppliers of solar pv array in China. With abundant experience, we are committed to providing high quality equipment made in China with competitive price. Welcome to buy durable solar pv array from our factory. Customized orders are welcome.
Product Overview
The solar photovoltaic array serves as the core power generation unit of the photovoltaic system for fermentation plants, composed of LONGi Hi-MO photovoltaic modules and a complete zinc-aluminum-magnesium alloy support system, custom-developed for the top of fermentation tanks in biochemical and chemical factories. Based on the photovoltaic effect, the array absorbs photon energy from sunlight to generate direct current, acting as the energy source of the entire photovoltaic system. A single fermentation tank can carry 55 pieces of 585Wp modules, with a total installed power of 32.18kW per array and an average daily power output of 130kWh. The generated electricity prioritizes powering fermentation tank loads, and surplus power is fed into the public grid to greatly cut industrial power costs. The whole array adapts to harsh industrial conditions including high temperature, high humidity, acid and alkali corrosion, complies with explosion-proof, fire protection and tank load-bearing standards, and will not occupy operation space of the plant.
Core Supporting Accessories
PV Modules
LONGi Hi-MO 585Wp modules, dimension 2278113430mm;
Full Set of Support Brackets
S350GD zinc-aluminum-magnesium upright columns, oblique beams, main beams, cantilever bracings, eight-point supports, pillar cross tie beams, etc.;
Fastening Accessories
Hot-dip galvanized module pressing blocks, U-bolts, flange nuts, column reinforcement plates, hot-dip galvanized column base plates;
Power Cables
PV1-F-1×4mm² special DC photovoltaic cables.
Craft & Product Advantages
- Superior Module Performance: Adopt top domestic brand LONGi with conversion efficiency over 24%, outstanding low-light power generation and low temperature coefficient to minimize power attenuation under high temperature. Complete warranty coverage includes 15-year material warranty and 30-year linear power output warranty, with initial annual attenuation ≤0.4% and power retention rate ≥87% after 30 years of operation for long-term stable power generation.
- Anti-corrosion Bracket Craft: All brackets are made of S350GD zinc-aluminum-magnesium alloy profiles, while column base plates adopt Q235B hot-dip galvanizing with 65μm anti-corrosion coating. The material resists acid, alkali, moisture and aging, perfectly fitting corrosive environments of chemical and fermentation workshops. High-strength rectangular tubes, U-shaped steel and angle steel form lightweight structures that meet fermentation tank load standards with strong wind and seismic resistance.
- Customized Adaptation Craft: Brackets are tailor-designed for each fermentation tank to precisely match tank load-bearing, heat dissipation and pipeline layout, while reserving sufficient maintenance space. Modular welded brackets enable easy installation and simple later operation & maintenance.
- Industrial Protection Craft: The whole array features dust-proof, high-temperature resistant and anti-corrosion performance. Different from civil photovoltaic arrays, it can operate stably long-term in high-corrosion fermentation and chemical industrial conditions with more reliable power output.
